| Interface | • 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+)
• AUTO Negotiation
• AUTO MDI/MDIX |
|---|
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Fan Quantity | Fanless |
|---|
| Physical Security Lock | Yes |
|---|
| External Power Supply | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
|---|
| Packet Forwarding Rate | 0.8928 Mpps |
|---|
| PoE Ports (RJ45) | • Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4
• Power Supply: 67 W |
|---|
| Mac Address Table | 2K |
|---|
| Jumbo Frame | 2 KB |
|---|
| Switching Capacity | 1.2 Gbps |
|---|
| Dimensions ( W x D x H ) | 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm) |
|---|
| Max Power Consumption | • 2.52 W (220 V / 50 Hz, no PD connected)
• 75.4 W (220 V / 50 Hz, with 67 W PD connected) |
|---|
| Max Heat Dissipation | • 8.59 BTU/h(no PD connected)
• 257.11 BTU/h(with 67 W PD connected) |
|---|
