| System Parameters |
|---|
| Comparison Mode: | 1:1/1:N |
| Comparison Time: | 1:1≤1s; 1:3000≤1.5s |
| Fingerprint Module: | Optical, Red Backlight |
| FRR (False Rejection Rate): | ≤0.01% |
| Card Reading Distance: | Mifare Card:≤50 mm |
| FAR (False Accept Rate): | ≤0.001% |
| Card Reading Mode: | Mifare Reading Module |
| Fingerprint Capacity: | 5,000 |
| Processor: | 32 Bit High-performance Processor |
| Device Interfaces |
|---|
| Communication Mode: | RS-485 |
| Transmission Rate: | 19200bps-N-8-1 |
| General |
|---|
| Mounting Method: | Surface Mounting |
| Alarm: | Tamper Alarm × 1 |
| Power Supply: | 12VDC |
| Prompt: | Buzzer |
| LED Indicator: | Power Indicator; Status LED Indicator |
| Protection Level: | IP 65 |
| Working Humidity: | 10% to 90% (Non-Condensing) |
| Working Temperature : | -40°C to +70°C (-40°F to +158°F) |
| Dimensions (L×W×H): | 62mm × 132mm × 44mm (2.44" × 5.20" × 1.73") |
