| System Parameters |
|---|
| Storage: | card information:
100,000 (200,000 expandable)
access control events :
300,000 (600,000 expandable) |
| Capacity: | 16M |
| Processor: | 32-bit |
| Device Interfaces |
|---|
| Accessible Card Reader: | 8 Card Readers (RS485 Interface) and 4 Card Readers (Wiegand Interface) Connectable |
| Uplink Communication Interface: | TCP/IP Network Interface and RS-485 Interface |
| Downlink Communication Interface: | RS-485 and Wiegand (W26/W34) |
| Output Interface: | Lock Relay×4, Alarm Relay×4 |
| Input Interface: | Alarm Input×4, Door Sensor×4, Exit Button×4, Case Input×8, Tamper Alarm ×1 |
| General |
|---|
| Working Voltage: | DC 12V/1A |
| Power Consumption: | ≤4W(Without Load); ≤100W(with Load) |
| LED Indicator: | Power Supply Status, Communication Status, Working Status |
| Certification: | CE, FCC |
| Working Humidity: | 10% to 90% (Non-Condensing) |
| Working Temperature : | -20°C to +65°C |
| Dimensions (L×W×H): | 450mm x 400mm x 100 mm |
