| MOUNTING HEIGHT | 1.1m min, 3.1 max, 2.1m-2.3m for optiomal detection |
| COVERAGE | 15m x 15m @ 90° |
| DETECTION ZONES | 20 QUAD element zones |
| PET IMMUNITY | Single pet up to 18kg or multiple pets up to 10kg total |
| RANGE SELECT | Selectable High/Low (15m/12m) |
| PULSE COUNT | Selectable 1–2 or 3–4. |
| VISUAL DISPLAY | Red Alarm LED |
| OPERATING VOLTAGE | 9 - 15 VDC |
| DIMENSIONS (H-W-D) | 85 x 66 x 45 mm |
| ALARM PERIOD | 5 seconds |
| WARM UP PERIOD | 30 seconds |
| CURRENT DRAW | 7mA |
| ALARM OUTPUT | Normally closed relay, dry contacts. Max. 100mA@24V |
| TAMPER OUTPUT | Normally closed dry contacts |
