| Control mode |
|---|
| Control mode: | IP-based |
| Audio Input/Output |
|---|
| Line In: | 1-ch, 3.5mm connector (2.0Vp-p, 1kΩ） |
| Audio Out: | 1-ch, 3.5mm connector (Linear, 600Ω) |
| External interface |
|---|
| Communication interface: | 1 RJ45 10M/100M/1000M adaptive Ethernet interface;
1 RS-232 interface;
1 RS-485 interface;
1 USB2.0 interface (for data storage and device upgrade) |
| General |
|---|
| LCD screen: | 7” TFT LCD monitor with touch panel |
| Joystick: | 3-axis joystick |
| Power supply: | 12VDC |
| Power consumption: | ≤15W |
| Working temperature: | -10°C ~ +55°C |
| Working humidity: | 10%~90% |
| Size: | 110mm (H)×193mm (W) ×435mm (D) |
| Weight: | 2Kg |
