| MOUNTING HEIGHT | 2.4 m for best coverage |
| COVERAGE | 12m x 12m pattern at floor level |
| PIR SENSOR | Dual element pyroelectric |
| RANGE SELECT | Selectable High/Low |
| PULSE COUNT | Selectable 1–2 or 3–4. |
| VISUAL DISPLAY | Red Alarm LED |
| OPERATING VOLTAGE | 9 - 15 VDC |
| DIMENSIONS (D-H) | 102 x 30 mm |
| ALARM PERIOD | 5 seconds |
| WARM UP PERIOD | 30 seconds |
| CURRENT DRAW | 15mA |
| ALARM OUTPUT | Normally closed relay, dry contacts. Max. 0.5A@24V |
| R.F.I. IMMUNITY | > 15V/m @ 10-1000MHz |
| TAMPER OUTPUT | Normally closed dry contacts |
